Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Maximum efficiency |
98.6% |
98.6% |
98.6% |
98.8% |
|
Chinese efficiency |
N/A |
98.2% |
N/A |
98.4% |
|
European efficiency |
98.3% |
98.3% |
98.3% |
N/A |
|
Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Maximum input power |
30,600 W |
30,600 W |
30,600 W |
40,800 W |
|
Maximum input voltage |
1000 V |
|||
|
Maximum input current (per MPPT) |
23 A |
|||
|
Maximum short-circuit current (per MPPT) |
34.5 A |
|||
|
Highest operating voltage |
1000 V |
|||
|
Lowest operating/startup voltage |
200 V/250 V |
|||
|
Max. inverter backfeed current to the array |
0 A |
|||
|
Full power MPPT voltage range |
580–850 V |
480–800 V |
480–800 V |
580–850 V |
|
Maximum number of inputs |
6 |
|||
|
Number of MPP trackers |
3 |
|||
|
Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Rated active power |
30,000 W (480 V, 50 Hz) |
30,000 W (400 V, 50 Hz) |
30,000 W (400 V, 50 Hz) |
36,000 W (480 V, 50 Hz) |
|
Maximum apparent power |
33,000 VA |
33,000 VA |
33,000 VA |
40,000 VA |
|
Maximum active power (cosφ = 1)a |
30,000 W |
30,000 W |
30,000 W |
40,000 W |
|
Rated output voltage |
277 V/480 V, 3W+PE |
220 V/380 V, 230 V/400 V, 3W+N+PE or 3W+PEb |
230 V/400 V, 3W+N+PE |
277 V/480 V, 3W+PE |
|
Adapted grid frequency |
50 Hz/60 Hz |
|||
|
Maximum output current |
40 A |
48 A |
48 A |
48 A |
|
Power factor |
0.8 leading ... 0.8 lagging |
|||
|
Maximum total harmonic distortion (rated power) |
< 3% |
|||
|
||||
|
Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Input DC switch |
Supported |
|||
|
Anti-islanding protection |
Supported |
|||
|
Output overcurrent protection |
Supported |
|||
|
Input reverse polarity protection |
Supported |
|||
|
PV string fault detection |
Supported |
|||
|
DC surge protection |
Type II |
|||
|
AC surge protection |
Type II |
|||
|
Insulation resistance detection |
Supported |
|||
|
Residual current monitoring unit (RCMU) |
Supported |
|||
|
Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Display |
LED, Bluetooth module+app, WLAN module+app, USB data cable+app |
|||
|
RS485 |
Supported |
|||
|
PLC (MBUS) |
Optional |
|||
|
Technical Specifications |
SUN2000-30KTL-A |
SUN2000-33KTL |
SUN2000-33KTL-E001 |
SUN2000-40KTL |
|---|---|---|---|---|
|
Dimensions (W x H x D) |
550 mm x 770 mm x 281 mm (including the mounting plate) |
|||
|
Net weight |
About 54 kg (excluding the mounting plate)/About 56 kg (including the mounting plate) |
|||
|
Operating temperature range |
–25°C to +60°C |
|||
|
Cooling |
Natural convection |
|||
|
Highest altitude |
4000 m |
|||
|
Humidity |
0%–100% RH |
|||
|
Input terminal |
Amphenol Helios H4 |
|||
|
Output terminal |
Waterproof cable connector+OT terminal |
|||
|
Ingress Protection Rating |
IP65 |
|||
|
Topology |
Transformerless |
|||
